Series & Specification
| Model | Powerbox Pro |
| Battery Type | LiFePO₄ |
| Nominal Battery Energy | 10.24 kWh |
| Operating Voltage | 44.8-57.6V |
| Nominal Voltage | 51.2V |
| Nominal Capacity | 200Ah |
| Nominal Power | 512kW |
| Peak Power | 10.24kW |
| Recommended Charge & Discharge C Rate | 0.5C |
| Recommended Charge/Discharge Current | 100A |
| Recommended Depth of Discharge (DOD) | 90% |
| Net Weight | 103kg |
| Dimension[W/D/H] | 555210928 mm |
| Charging Temp. Range | 0--55°C |
| Discharging Temp. Range | -20--55°C |
| Communication | CAN/RS485 |
| WiFi Module | Optional |
| Cycle Life * | >6000 Cycles |
| Protection Level | IP65 |
| Expansion ** | Up to 50 units in parallel(This version is for production after September 2024) |
| Certification & Safety Standard | UN38.3/CE-EMC/IEC62619/IEC62040/UKCA/CEC |
| Compatible Inverters | Solis/Deye/Lupoower/Voltronic/Hoymiles/Growatt/Goodwe/SMA/Victron/Ingeteam/Delios/SAJ/APS etc. |
* Test conditions: 0.2C Charging & Discharging, @25°C, 90% DOD
** World batteries are mixed with the new version, the quantity of new version batteries: Qty(new)=50-Qty(old)*2
Note: This specification is only suitable for Vietnam Market. Powerbox Pro is available for OEM/ODM orders.
